Assembly Available : Custom Built

• Standard type
• Mineral insulated

High Temperature Thermocouple Cable

Sheath : SS-304, SS-310, SS-316, SS-321, SS - 446,Inconel - 600, Incaloy - 800, Titanium, Tentalum, Tungston, Hast - Alloy - C etc.
Sheath Diameter : 0.5mm to 22mm
Element : Simplex - Duplex - Triplex
Thermowell : Bar - stock or fabricated as per DRG / application available in different metals : plain or coated.

Application : Temperature Sensing

• Chemical Industries
• Petroleum / Oil Industries
• Textile
• Engineering
• Plastic
• Defence
• Space
• Foundry etc.

Insertion Probes	Averaging Sensor
Thermocouples & RTD Probes for penetrating meats, fish, poultry & other food products.	RTD sensor to measure cross - sectional temperatures in large air ducts.
Cip Sanitary Connected	Wet / Dry Bulb Tanks
High accuracy RTD's for use in food & pharmaceutical sanitary process applications.	Psychometric temperature & humidity measurement in smokehouses & lumber drying kilns.
Magnet Sensor	Watse Incineration
Spring loaded magnet attached thermocouples for metal surface temperature.	Thermocouples with special protection tubes for high temperature corrosive service.
Cerite	Indicating Bayonet
Thermocouples with non-wetting protection tubes for molten aluminium.	Thermocouples with colour indication when properly seated in place.
High Temperature Service	Textile "T" Sensor
Platinum thermocouples in high temperature sheaths for vacuum furnace service.	RTD sensor for "Godet" temperature measurement in textile fiber processing.
Banbury & Aggregate Mixer	Heat Tracing / Tube Skin
Thermocouples with hardened tool steel, carbide, tungsten or chrome coated tips for abrasive service.	RTD's or thermocouples with weld pads for pipelines or boiler tube skin temperature measurement.
